Tenda F6 User Manual

44
9.5 DMZ host
A DMZ host on a LAN can be accessed by the internet users without limit. It is especially used for
video conferences and online games. You can set a computer with these requirements as a DMZ
host for better user experience.
Choose Advanced, and move to DMZ Host module to access the configuration page. By default, it
is disabled. It shows as the following figure when you enable it.

A DMZ host is not protected by the firewall of the router. A hacker may leverage the DMZ host to
attack your LAN. Therefore, enable the DMZ function only when necessary.

Manually set the IP address of the LAN computer that functions as a DMZ host (Refer to IP-MAC
binding function), as a changeable IP address may result in DMZ function failures.

Security software, antivirus software, and the built-in OS firewall of the computer may cause DMZ
function failures. Disable them when using the DMZ function. If the DMZ function is not required,
you are recommended to disable it and enable your firewall, security, and antivirus software.
Configuration procedure
Step 1 Choose Advanced, and move to DMZ Host module to enter the configuration page.
Step 2 Set Host IP Address to the IP address of a computer that you want to set as the DMZ host.
Step 3 Click OK at the bottom of the page.
----End

Tenda F6 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Antennas quantity	4
Antenna gain level (max)	5 dBi
Product type	Tabletop router
Product color	White
LED indicators	WLAN
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Frequency band	2.4 GHz
Firewall security	Support Oray.com，88ip
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Certification	CCC, CE
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
DSL WAN	No
WAN connection type	RJ-45
Power source type	DC
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	211 mm
Width	204 mm
Height	147.5 mm
