Tenda N301 User Manual

36
Verify that one of the new routers’ ports (any port) is connected to a LAN port of the original router which can
access the internet.
3.6 Parental Control
This function enables you to control internet connectivity availability and content accessibility for devices
connected to the router, ensuring healthy internet usage.
To implement parental control, perform the following procedure:
Step 1 Choose Parental Controls.
Step 2 All the devices connected to the router are listed.
Step 3 Click to change it to the state corresponding to the device to which parental control
must be applied.
Step 4 Set the parameters to specify the time when the internet is accessible to the device.
Step 5 Set the websites accessible or inaccessible to the device.
---End
The following table describes the parameters.
Parameter
Description
Device Name
It specifies the name of a device. Click to change the device name.
IP Address
It specifies the IP address assigned to a device.

Tenda N301 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Rack mounting	No
Frequency range	2.4 - 2.472 GHz
WLAN data transfer rates supported	11, 54, 300 Mbit/s
Ethernet LAN (RJ-45) ports	3
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK, WPS
Antennas quantity	2
Antenna gain level (max)	5 dBi
Product color	White
Power source type	DC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoH
Cables included	LAN (RJ-45)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	127.4 mm
Width	90.5 mm
Height	26 mm
Weight	- g
