Tenda N301 User Manual

2
1.3 Appearance
1.3.1 LED Indicators
States of LED indicators of the router that is powered on
LED
Indicator
State
State Description
SYS
Blinking
The system is working properly.
WiFi
Solid on
The WiFi function is enabled.
Blinking
The router is transmitting or receiving data over the WiFi
network.
Off
The WiFi function is disabled.
1, 2, and 3
Solid on
The port is properly connected using an Ethernet cable.
Blinking
The LAN port is connected.
Off
The port is not connected or the connection is faulty.
WAN
Solid on
The port is properly connected using an Ethernet cable.
Blinking
The port is transmitting of receiving data.
Off
The port is not connected or the connection is faulty.

Tenda N301 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Rack mounting	No
Frequency range	2.4 - 2.472 GHz
WLAN data transfer rates supported	11, 54, 300 Mbit/s
Ethernet LAN (RJ-45) ports	3
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK, WPS
Antennas quantity	2
Antenna gain level (max)	5 dBi
Product color	White
Power source type	DC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoH
Cables included	LAN (RJ-45)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	127.4 mm
Width	90.5 mm
Height	26 mm
Weight	- g
