Tenda N301 User Manual

38
---End
3.7 Advanced Functions
The router provides advanced functions to address tailored requirements.
3.7.1 DHCP Reservation
Generally, IP addresses assigned by the router to devices are changeable. Some functions, such as the
DMZ host and virtual server functions, require static device IP addresses. In this case, you can use the
DHCP reservation function to bind fixed IP addresses with the devices involved in the functions.
To configure the DHCP reservation function, choose Advanced > Static IP (DHCP Reservation).
Procedure
Step 1 Set IP Address to an IP address between Start IP and End IP of the router’s DHCP server.
(Check this range on Administration > LAN Parameters page.)
Step 2 Set MAC Address to the MAC address of the device that requires a fixed IP address.
Step 3 (Optional) Enter a name for the device for easy recognition.
Step 4 Click , and click OK.

Tenda N301 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Rack mounting	No
Frequency range	2.4 - 2.472 GHz
WLAN data transfer rates supported	11, 54, 300 Mbit/s
Ethernet LAN (RJ-45) ports	3
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK, WPS
Antennas quantity	2
Antenna gain level (max)	5 dBi
Product color	White
Power source type	DC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Certification	FCC, CE, RoH
Cables included	LAN (RJ-45)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	127.4 mm
Width	90.5 mm
Height	26 mm
Weight	- g
