Toro Multi Pro 5800-G User Manual

1
AssemblingtheSprayer
TankFillFitting
Partsneededforthisprocedure:
1
Quick-disconnecttting
Procedure
Note:Tocompletethisprocedure,youwillneedto
supplyahosewith1inchmalenationalpipethread
(NPT)ttingandPTFEthreadsealant.
1.Attheforward,rightsideofthetankcover,
removethe2hairpinsthatsecurethelatchesfor
thequick-disconnectcouplingfortheanti-siphon
llreceptacle(Figure3).
g242085
Figure3
1.Quick-disconnecttting3.Latches(quick-disconnect
coupling)
2.Hairpins
2.Rotatethelatchesopentounlock
thequick-disconnectttingfromthe
quick-disconnectcoupling(Figure3).
3.Removethequick-disconnectttingfromthe
quick-disconnectcoupling(Figure3).
4.Closethelatchesandinstallthehairpinsinto
theangesofthequick-disconnectcoupling
(Figure3).
5.ApplyPTFEthreadsealant(Figure4)tothe
threadsofthellhosetting(1inch—national
pipethread).
g191615
Figure4
1.PTFEthreadsealant
3.Quick-disconnecttting
2.Fillhosetting(1
inch—nationalpipe
thread)
6.Threadthequick-disconnectcouplingontothe
llhoseandtightenitbyhand(Figure4).
2
CheckingtheSection-Hinge
Springs
NoPartsRequired
Procedure
Important:Operatingthespraysystemwith
thesection-hingespringsundertheincorrect
compressioncoulddamagetheboomassembly.
Measurethespringsandusethejamnutto
compressthespringsto4cm(1-1/2inches)if
necessary.
Thesprayerisshippedwiththesectionextensions
swungforwardtofacilitateshippingthemachine.
Thespringsarenotfullytightenedatthetimeof
manufacturetoallowthesectionstobeinthisposition
fortransit.Beforeoperatingthemachine,thesprings
mustbeadjustedtothecorrectcompression.
1.Ifnecessary,removethepackingcomponents
thatsecuretherightandleftextensionsections
duringshipping.
2.Supportthesectionswhiletheyareextendedto
thesprayposition.
3.Atthesectionhinge,measurethecompression
oftheupperandlowerspringswhilethesections
areintheirextendedposition(Figure5).
A.Allspringsmustbecompresseduntilthey
measure4cm(1-1/2inches).
B.Usethejamnuttocompressanyspringthat
measuregreaterthan4cm(1-1/2inches).
13
