Toro Multi Pro 5800-G User Manual

Pre-Maintenance
Procedures
CAUTION
Ifyouleavethekeyinthestarterswitch,
someonecouldaccidentlystarttheengine
andseriouslyinjureyouorotherbystanders.
Removethekeyfromthestarterswitchbefore
youdoanymaintenance.
RaisingtheSprayer
Wheneverrunningtheengineforroutinemaintenance
and/orenginediagnostics,therearwheelsofthe
sprayershouldbe25mm(1inch)offthegroundwith
therearaxlesupportedonjackstands.
DANGER
Asprayeronajackmaybeunstableandslip
offthejack,injuringanyonebeneathit.
•Alwaysremovethekeyfromthestarter
switchbeforegettingoffthesprayer.
•Blockthetireswhenthesprayerisona
jack.
•Supportthemachinewithjackstands.
Thejackingpointatthefrontofthesprayerisunder
thefrontaxle,directlyundertheleafsprings(Figure
60).
g203110
Figure60
1.Frontjackingpoints
Thejackingpointattherearofthesprayerison
therearsidewheretheboomsupportsarelocated
(Figure61).
g203111
Figure61
1.Rearjackingpoints
AccessingtheEngine
RemovingtheForwardHeatShield
1.Engagetheparkingbrake,shutoffthespray
pump,shutofftheengine,andremovethekey.
2.Raisethefrontandbackofthemachineand
supportitwithjackstands;refertoRaisingthe
Sprayer(page50).
3.Removethe6hex-headboltsand6washers
thatsecurethefront,forwardheatshieldtothe
chassisandremovetheshield(Figure62).
Note:Retainthebolts,washers,andheat
shieldforinstallationinInstallingtheForward
HeatShield(page51).
g028168
Figure62
1.Forwardheatshield
3.Frontofthemachine
2.Hex-headboltsand
washers
50
