Note:Tosealthetank,closethecoverand
rotatethefronthalfclockwise.
Important:Afterllingthetankfortherst
time,checkthetankstrapsforanyplay.
Tightenasnecessary.
InspectingtheTankStraps
ServiceInterval:Beforeeachuseordaily—Check
thetankstraps.
Important:Overtighteningthetankstrap
fastenerscanresultindeforminganddamaging
thetankandstraps.
Important:Wheneverpossible,donotuse
reclaimedwater(graywater)inthespraytank.
1.Fillthemaintankwithwater.
2.Checktoseeifthereisanymovementbetween
thetankstrapsandthetank(Figure28).
g028263
Figure28
1.Reartankstrap4.Forwardtankstrap
2.Bolt
5.Frontofthemachine
3.Flangedlocknut
3.Ifthetankstrapstloosetothetank,tightenthe
angedlocknutsandboltsatthetopofstraps
untilthestrapsareushwiththesurfaceofthe
tank(Figure28).
Note:Donotovertightenthetankstrap
hardware.
Calibratingthe
Section-BypassValves
ManualModeOnly
Important:Whenoperatinginapplicationrate
mode,youmustsetthesection-bypassvalvesto
theclosedposition.
Important:Wheneverpossible,donotuse
reclaimedwater(graywater)inthespraytank.
Beforeusingthesprayerforthersttime,whenever
youchangethenozzles,orasneeded,calibratethe
sprayerow,speed,andsetthesectionbypass.
Important:Selectanopenatareatoperform
thisprocedure.
PreparingtheMachine
1.Fillthespraytankhalfwaywithcleanwater.
2.Lowerthespraysections.
3.Engagetheparkingbrake.
4.Setthespraycontrolswitchtomanual.
5.Setthe3sectionswitchestotheONposition,
butleavethemastersectionswitchintheOFF
position.
6.Setthespray-pumpswitchtotheONposition,
andturnontheagitation.
7.OntheInfoCenter,navigatetotheCalibration
screenandselectT estSpeed;referto
SimulatingaT estSpeedintheSoftwareGuide
fortheMultiPro5800-Dand5800-Gturfsprayer
withExcelaRatespraysystem.
A.Pressbuttons3or4toraiseorlowerthe
simulatedspeedto5.6km/h(3.5mph).
B.Pressbutton4totoggleONtestspeed
simulation.
C.Pressbutton5tosaveandexittheTEST
SPEEDscreen.
AdjustingtheSectionBypass
Valves
1.Usingtheapplication-rateswitch,adjustthe
applicationrateaccordingtothetablethat
follows.
NozzleApplicationRateTable
NozzleColorSI(Metric)
English
Turf
Yellow
159L/ha
17gpa0.39gpk
Red
319L/ha
34gpa0.78gpk
Brown
394L/ha
42gpa0.96gpk
Gray478L/ha
51gpa1.17gpk
White
637L/ha
68gpa1.56gpk
Blue
796L/ha
85gpa1.95gpk
Green1,190L/ha
127gpa2.91gpk
2.Turnofftheleft-sectionswitchandadjustthe
section-bypassknob(Figure29)untiltherate
displayedisatthepreviouslevelaccordingto
thetable.
28
