Toro Multi Pro 5800-G User Manual

g002014
Figure70
RightBoom
1.Greasetting
3.Wipeoffexcessgrease.
4.Repeattheprocedureforeachboompivot.
GreasingtheActuator-Rod
Bearings
ServiceInterval:Every400hours/Yearly(whichever
comesrst)
GreaseType:No.2lithiumgrease.
1.LowertheouterspraysectionstotheSPRAY
position.
2.Removethehairpinfromtheclevispin(Figure
71).
3.Liftuponthesectionandremovetheclevis
pinandslowlylowerthesectiontotheground
(Figure71).
4.Inspecttheclevispinforanydamage,replace
ifnecessary.
g013780
Figure71
1.Actuator4.Hairpin
2.Actuatorrod
5.Clevispin
3.Boom-pivot-pinhousing
5.Swiveltherod-endbearingandapplygrease
intothebearing(Figure72).
Note:Wipeoffexcessgrease.
g002015
Figure72
RightBoom
1.Greasetherod-endbearing
6.Liftthespraysectiontoalignthepivotwiththe
actuatorrod.
7.Whilesupportingthespraysection,insertthe
clevispinthroughbothboompivotandactuator
rod(Figure71).
8.Withthepininplace,releasethespraysection
andsecurethepinwiththehairpinremoved
previously.
54
