Programming Module Components
1. Programming Module
2. Programming Dial - To select irrigation functions.
Control Dial Positions:
3. Run Time
- To set station run time duration.
4. Start Time
- To set start times(s) for automatic watering program.
5. Water Days
- To set individual days of the week for automatic watering.
6. Watering Budget
- To set Watering Budget adjustment for run time
duration.
7. P+ and P- Buttons - Select next/previous irrigation programs.
8. Auto Button
- To select automatic operation.
9. Help Button
- To show help text on LCD display.
10. Settings Button
- To set Controller’s parameters.
11. Test Button
- To run a program to check hydraulic and electric station
operation.
12. Manual Program(s) Button
- To select watering programs for manual
operation.
13. Manual Station(s) Button
- To select station(s) for manual operation.
14. Pause Button
- Turn o and prevents automatic station operation.
15. Start/Stop Button
- To start or stop manual program(s) and station(s) and
test program(s).
16.
and Button - Press to increase or decrease display number values and
various functions.
17.
and Button - Press to select next or previous function parameter.
18. Reset Button - Momentarily insert a clip to press the hidden Reset button to
restart operations.
19. LCD Display
20.
Symbol - Displayed when the Time duration shown is in minutes and
seconds.
21.
Symbol - Displayed when 24 VAC is missing or the Control Module is
removed from the Back Module.
22.
Symbol - Diplayed when automatic irrigation is on Pause.*
23.
Symbol - Displayed when sensor is active.*
24.
Symbol - Displayed when a Watering Budget run time duration adjustment
is in use.
25.
Symbol - Displayed when 12H time format is used.
26.
Symbol - Displayed when irrigation currently on.
27.
Symbol - Displayed to identify the number of the selection within a
function.
28.
2-digit - Number representing the shown selection.
29.
Symbol - Diplayed when an irrigation program is selected.
30.
1-Character - Identifies the irrigation Program selected or M for Master
Valve.
31.
10-Character - Multi-language Text for function description and help
info.
32.
Main Display - Shows various time values and controller information.
33. DB15 connector to Back Module.
34. Wi-Fi Module (optional).
35. USB Type A Plug for connecting the Wi-Fi Module (optional).
* When both displayed, Rain Sensor is active
