H-1
APPENDIX H
Appendix H
Internal Modem Guide
This appendix describes how to install and the remove the internal modem.
CAUTIONS: 1. Do not remove the base cover except to remove or
install the internal modem or to check the PTT label.
2. Do not disassemble the computer beyond the steps
described in this instruction or touch any components
not specifically described.
3. Always remove the Battery Pack and disconnect the AC
Adaptor before removing the base cover.
4. Be careful not to drop any screws or other foreign
matter into the computer. Metal or other foreign matter
can damage the computer.
Installing the internal modem
NOTE: The internal modem is preinstalled. The following is for informa-
tion only.
To install the modem board, follow the steps below.
1. Save your data, quit Windows and turn off the power.
2. Disconnect the AC Adaptor and any other peripheral devices.
3. Turn the computer upside down and remove the Battery Pack.
4. Remove two screws securing the HDD pack cover and remove the HDD pack.
5. Remove fifteen screws (one screw has a rubber cover). Do not remove the
screws securing the memory module.
6. Remove the bottom cover.
7. Connect the modem cable.
8. Install the modem and secure it with two screws.
9. Seat the bottom cover and secure fifteen screws.
To Next Page
