6-12
User's Manual
POWER AND
POWER-UP MODES
Removing the Battery Pack
To replace a discharged Battery Pack, follow the steps below.
CAUTION: When handling Battery Packs, be careful not to short circuit
the terminals. Also do not drop, hit or otherwise apply impact; do not
scratch or break the casing and do not twist or bend the Battery Pack.
1. Save your work.
2. Turn the computer’s power off. Make sure the Power indicator is off.
3. Remove all cables connected to the computer.
4. Turn the computer upside down with the back of the computer facing you.
5. Slide the battery lock to free the Battery Pack for removal.
6. Fit your finger into the indentation next to the Battery Pack and lift it out.
CAUTION: For environmental reasons, do not throw away a spent
Battery Pack. Please return spent Battery Packs to your TOSHIBA
dealer.
Figure 6-1 Removing the Battery Pack
BATTERY LOCK
BATTERY PACK
INDENTATION
To Next Page
