THE GRAND TOUR
User's Manual
2-6
Battery lock A sliding lock prevents inadvertent release of the Battery
Pack.
Speaker The speaker emits sound generated by your software as
well as audio alarms, such as low battery condition,
generated by the system.
Front with the display open
Figure 2-6 shows the front of the computer with the display open. To open the
display, push the display latch on the front of the computer and lift the display up.
Position the display at a comfortable viewing angle.
Figure 2-6 The front with the display open
DISPLAY SCREEN
POWER
BUTTON
TOSHIBA CONSOLE
BUTTON
INTERNET
BUTTON
DISPLAY
HINGE
DISPLAY HINGE
TOUCH PAD CONTROL BUTTONS
TOUCH PAD
SENSOR
SWITCH
