OPERATING BASICS
4-13
CAUTION: If you are using the computer in Japan, technical regulations
described in the Telecommunications Business Law require that you
select Japan region mode. It is illegal to use the modem in Japan with
any other selection.
Connecting
To connect the internal modem cable, follow the steps below.
WARNING: The modular cable that comes with the computer must be
used to connect a modem. Connect the end of the modular cable with the
core to the computer.
CAUTIONS: 1. In case of a lightning storm, unplug the modem cable
from the telephone jack.
2. Do not connect the modem to a digital telephone line.
A digital line will damage the modem.
1. Plug one end of the modular cable into the modem jack.
2. Plug the other end of the modular cable into a telephone jack.
Figure 4-11 Connecting the internal modem
CAUTION: Do not pull on the cable or move the computer while the
cable is connected.
NOTE: If you use a storage device such as a CD-ROM drive or HDD
connected to a 16-bit PC card, modem speed might be slow or communi-
cation might be interrupted.
Using the internal modem
