e-STUDIO162/162D/151/151D TEST COMMAND, TROUBLE CODES 10 - 3
4. Descriptions of various test commands
66 34 Communication time measurement (Executable only
when the FAX is installed.)
37 Speaker sound volume setting (Executable only when
the FAX is installed.)
38 Time setting/check (Executable only when the FAX is
installed.)
41 CI signal check (Executable only when the FAX is
installed.)
Main
code
Sub
code
Contents
Main
code
Sub
code
Contents Details of function/operation
1 01 Mirror scan (SCAN CHK) [Function]
When [OK (ENTER)/START] key is pressed, the home position is checked and the mirror base per-
forms full scan at the speed of the set magnification ratio.
During operation, the set magnification ratio is displayed.
The mirror home position sensor status is displayed with the “COPY mode lamp”. (When the mirror is
in the home position, the lamp lights up.)
During operation, the copy lamp lights up.
When [C] key is pressed, if the operation is on the way, it is terminated and the machine goes to the
sub code entry standby mode.
[Operation]
02 Mirror home position sensor
(MHPS) status display
(MHP-SENSOR)
[Function]
Monitors the mirror home position sensor, and makes the "COPY mode lamp" turn on during the sen-
sor ON status.
[Operation]
06 Mirror scan aging (SCAN
AGING)
[Function]
When [OK (ENTER)/START] key is pressed, the mirror base performs full scan at the speed of the set
magnification ratio.
During operation, the set magnification ratio is displayed.
After 3sec, the mirror base performs full scan again.
∗
When [OK (ENTER)/START] key is pressed once, the ready lamp remains OFF.
The mirror home position sensor status is displayed on the "COPY mode lamp." (The lamp is ON
when the mirror is in the home position.)
During aging, the copy lamp is ON.
[Operation]
The operation is similar to test command 1-01.
2 01 Single Paper Feeder (ADF)
aging (ADF AGING)
(Disabled when set to OC)
(Executable only when the
ADF is installed.)
[Function]
When [OK (ENTER)/START] key is pressed, the set magnification ratio is acquired and single-face
document transport is performed in the case of ADF or duplex document transport in the case of R-
ADF.
However, the operating conditions don't matter and the operation is not stopped even in case of a
jam. Also the magnification ratio is displayed on the LCD.
[Operation]
The operation is similar to test command 1-01.
1) Initial display
2) [ZOOM]
2) [
←
]
2) [
→]
3) [OK (ENTER)/START]
01-01 SCAN CHK
- 100% +
01-01 SCAN CHK
- 78% +
01-01 SCAN CHK
- 99% +
01-01 SCAN CHK
- 101% +
01-01 SCAN CHK
EXECUTING... - 78% +
1) Initial display
01-02 MHP-SENSOR
EXECUTING...
e-STUDIO162_151.book 3 ページ ２００４年１２月２日 木曜日 午後９時３７分
