0-20-2
TYPE OF LPG DEVICES
1. Types of LPG cylinders
2. Types of LPG cylinder brackets
Gas weight Cylinder length Specification
Pneumatic
models
Cushion
models
15 kg (33.1 lb) 637 mm (25.1 in)
General purpose — STD
With level gauge and quick coupling — OPT
20 kg (44.1 lb) 797 mm (31.4 in)
General purpose STD —
With level gauge and quick coupling OPT —
Cylinder
Removal/installation method Bracket opening direction
Fuel hose connecting
position
Weight
External
diameter
20.0 kg
(44.1 lb)
797 mm
(31.4 in)
Sinple type (STD)
Swing down type (OPT) Right Bottom
15.0 kg
(33.1 lb)
637 mm
(25.1 in)
nnn
00.book 2 ページ ２００７年２月２２日 木曜日 午後４時４５分
LPG Device for 4Y-E Engine
Section 1.3.0

Toyota 8FGCU30 Specifications

General

Model	8FGCU30
Category	Forklifts
Engine Type	Internal Combustion
Load Capacity	6, 000 lbs
Maximum Lift Capacity	6, 000 lbs
Tire Type	Pneumatic
Fuel Type	Gasoline/LPG
Power Source	Internal Combustion
Engine Model	Toyota 4Y
Mast Type	3-stage
