Toyota 8FGCU30 User Manual

1-11
REGULATORS SYSTEM COMPONENTS
LPG Cutoff Device
The solenoid valve for slow path control is integrated with the regulator. The solenoid valve is opened and closed
according to the engine speed, starter signal etc. detected by means of engine ECU. When the ignition switch is ON,
with the engine not running, the valve is closed not to flow LPG to the adapter.
Ignition
switch
ST
ON
AM
EFI
main
relay
Battery
LPG
Solenoid
relay
Slow
solenoid
Main
solenoid
Engine ECU
Gasoline
Starter
relay
Starter
motor
Igniter
LPG-
Gasoline
switch
LPG
01.book 11 ページ ２００７年２月２２日 木曜日 午後４時４６分
LPG Device for 4Y-E Engine
Section 1.3.1

Toyota 8FGCU30 Specifications

General

Model	8FGCU30
Category	Forklifts
Engine Type	Internal Combustion
Load Capacity	6, 000 lbs
Maximum Lift Capacity	6, 000 lbs
Tire Type	Pneumatic
Fuel Type	Gasoline/LPG
Power Source	Internal Combustion
Engine Model	Toyota 4Y
Mast Type	3-stage
