ANALYZER MENU SCREEN LIST
ANALYZER MENU screen Display item Description
DIAG MEMORY 1. - 10. Indications of errors occurred
I/O ENGINE CTRL IGSW Key switch (IG)
STA Key switch (ST)
BATT Battery voltage
G/LP Fuel changeover switch
SEL Fuel specification discrimination signal
ADJ Engine specification discrimination signal
MREL EFI main relay drive signal
FC Circuit opening relay drive signal
LPR LP gas main relay drive signal
LFC LP gas slow solenoid drive signal
OXHT O
2
sensor heater drive signal
THA Intake temperature sensor voltage
THW Coolant temperature sensor voltage
PIM Intake pipe negative pressure sensor voltage
VPA1 Accelerator sensor (1) voltage
VPA2 Accelerator sensor (2) voltage
PA Accelerator opening angle
VTA1 Throttle position sensor (1) voltage
VTA2 Throttle position sensor (2) voltage
TA Throttle opening angle
IM Electronic throttle motor current
NE Engine speed
IGT Ignition timing (spark advance amount)
OX O
2
sensor voltage
VF VF voltage (LPG/CNG)
LINJ Injector correction value (LPG/CNG)
FCM Air-fuel ratio motor correction value (LPG/CNG)
