HOW TO USE THIS MANUAL
EXPLANATION METHOD
1. Operation procedure
(1) The operation procedure is described in either pattern A or pattern B below.
Pattern A: Explanation of each operation step with illustration.
Pattern B: Explanation of operation procedure by indicating step numbers in one illustration, followed by
explanation of cautions and notes summarized as point operations.
Example of description in pattern B
DISASSEMBLY·INSPECTION·REASSEMBLY
Tightening torque unit T = N·m (kgf·cm) [ft·lbf]
Disassembly Procedure
1 Remove the cover. [Point 1]
2 Remove the bushing. [Point 2]
3 Remove the gear.
Point Operations
[Point 1]
Disassembly:
Put a match mark when removing the pump cover.
[Point 2]
Inspection:
Measure the bush inside diameter.
Limit: 19.12 mm (0.7528 in)
• Step Nos. are partially sometimes omitted in
illustrations.
• When a part requiring tightening torque
instruction is not indicated in the illustration, the
part name is described in the illustration frame.
T = 46.1 ~ 48.1
(470 ~ 490)
[34.0 ~ 35.5]
à Operation explained later
Ã
Explanation of key point for operation with an illustration
To Next Page
