Toyota 8FGCU30 User Manual

1-241-24
SPECIFICATIONS
Battery type list (The battery is selected according to the equipped engine).
Engine
Specifications
4Y 1DZ-II
STD
GR35
(JIS 55D23L)
GR24R
(JIS 80D26L)
Voltage V 12 ←
5 hour rated capacity Ah 48 55
Specific gravity of battery fluid in use
(at 20°C (68°F))
1.280 ←
Battery weight kg (lb) 16.2 (35.7) 19.0 (41.9)
Engine
Section 1

Toyota 8FGCU30 Specifications

General

Model	8FGCU30
Category	Forklifts
Engine Type	Internal Combustion
Load Capacity	6, 000 lbs
Maximum Lift Capacity	6, 000 lbs
Tire Type	Pneumatic
Fuel Type	Gasoline/LPG
Power Source	Internal Combustion
Engine Model	Toyota 4Y
Mast Type	3-stage
