1-17
7. Install the element.
Install the evacuator valve in the illustrated direction.
CLOGGING WARNING SYSTEM
INSPECTION (OPT)
1. Warning lamp inspection
(1) Check that the air cleaner warning lamp comes on when
the ignition key switch is turned ON and goes out when
the engine starts.
2. Individual inspection
(1) Use a mity vac to apply a negative pressure to the
vacuum switch, and inspect for continuity.
Standard
4Y engine vehicle
2630~3218 Pa (270~330 mmAq) (19.9~24.3 mmHg):
continuity exists
1DZ-II engine vehicles
6904~8042 Pa (704~820 mmAq) (51.7~60.3 mmHg):
continuity exists
25°
Engine
Section 1

Toyota 8FGCU30 Specifications

General

Model	8FGCU30
Category	Forklifts
Engine Type	Internal Combustion
Load Capacity	6, 000 lbs
Maximum Lift Capacity	6, 000 lbs
Tire Type	Pneumatic
Fuel Type	Gasoline/LPG
Power Source	Internal Combustion
Engine Model	Toyota 4Y
Mast Type	3-stage
