Trane Horizon OADG Series User Manual

Unit Clearances, Curb Dimensions, and Dimensional Data
OAU-SVX007A-EN 27
Notes:
• Certain options require auxiliary cabinet. Refer to product-
specific unit submittals.
• Sound attenuation package will add 10.01 in. to the height
of the condenser fan section. Refer to project-specific unit
submittals.
OAN Units
Unit Clearances
Figure 22. Unit dimensional data for OAK 12–30 tons,
horizontal supply and horizontal return with
ERV (in.)
39.89
106.21 54.38
4.00
RA/SA
duct flange
(Typical)
13.97
TOP VIEW
33.75
94.21
83.57
60.00
80.57
34.00
60.47
5.00
98.11
FRONT VIEW
SA
RA
35.47
32.88
43.02
34.00
8.22
2.08
9.94
SA
80.57
SA
10.91
27.68
RA
35.50
RA
29.20
64.52
21.41
204.68
237.06
20.35
233.88
21.00
6.04
204.18
RIGHT VIEW
Figure 23. Typical installation clearances for OAN unit
Clearance 60”
Clearance 48”
Clearance from
top of unit 72”
Clearance 48”
Clearance 36”
3’0”
3’0”
4’0”
4’0”
