Unit Clearances, Curb Dimensions, and Dimensional Data
OAU-SVX007A-EN 29
Dimensional Data
Figure 29. Unit dimensional data for OAN 30–54 tons,
vertical supply and vertical/no return without
ERV
Figure 30. Unit dimensional data for OAN 30–54 tons
with auxiliary cabinet, vertical supply and
vertical return with ERV
144.00
67.00
74.63
144.17
42.00
92.07
98.49
48.62
62.00
67.00
74.63
98.49
144.00
92.07
144.17
35.84
Figure 31. Unit dimensional data for OAN 30–54 tons,
horizontal supply and vertical/no return (in.)
144.17
2.88
SA duct flange`
TOP VIEW
95.07
92.07
67.00 31.54
98.75
67.47
4.97
98.54
FRONT VIEW
SA
Gas
inlet
Condensate
drain
41.89
186.33
19.06
35.57
28.56
SA
42.00
92.07
144.00
9.46
SA
144.45
48.52
41.47
2.08
11.21
RIGHT VIEW
