Unit Weight and Rigging
64 OAU-SVX007A-EN
Corner Weight
OAB*036 1608 2352 68.8 24.8 36% 17% 34% 14%
OAK*240 3421 6240 56.7 36.9 26% 13% 34% 28%
OAB*048 1608 2352 63.6 24.1 32% 22% 32% 14%
OAB*060 1608 2352 65.5 24.3 29% 24% 29% 18%
OAB*072 1608 2352 65.2 24.2 29% 25% 29% 18%
OAB*084 1608 2352 63.0 24.0 22% 32% 23% 23%
OAB*096 1608 2352 65.5 24.3 29% 24% 29% 18%
OAB*108 1608 2352 66.9 24.6 29% 24% 28% 19%
OAG*120 3199 4730 84.4 35.5 26% 26% 24% 24%
OAG*144 3199 4730 83.6 35.3 24% 28% 23% 25%
OAG*180 3199 4730 82.5 35.4 23% 29% 23% 25%
OAG*210 3199 4730 84.0 35.0 24% 29% 21% 26%
OAG*240 3199 4730 83.6 35.3 24% 28% 23% 25%
OAG*264 3199 4730 83.6 35.3 24% 28% 23% 25%
OAG*300 3199 4730 83.6 35.3 24% 28% 23% 25%
OAG*360 3199 4730 83.6 35.3 24% 28% 23% 25%
OADG010 2970 4207 66 38.3 22% 18% 37% 23%
OADG012 2970 4207 62.5 40.2 23% 13% 44% 20%
OADG015 2970 4207 59.5 40.2 22% 15% 45% 19%
OADG017 3170 4407 60.5 39.9 22% 15% 44% 19%
OADG020 3170 4407 60.1 39.8 21% 16% 43% 21%
OANG040 7327 9888 106.8 49.9 25% 27% 28% 20%
OANG045 7327 9888 106.8 49.9 25% 27% 28% 20%
OANG050 7327 9888 106.8 49.9 25% 27% 28% 20%
OANG055 7674 10282 115.9 49.9 25% 27% 28% 20%
OANG060 7674 10282 115.9 49.9 25% 27% 28% 20%
OANG070 7990 10660 120.5 50.0 25% 27% 28% 20%
OANG080 8147 10834 125.0 50.5 25% 27% 28% 20%
(a) Refer to Figure 102, p. 66 and Figure 103, p. 66 for corner locations.
Table 2. Typical unit weight, center of gravity, and corner weights (percentage of total weight) - air cooled DX units with
powered exhaust but without ERV (continued)
Model Number
Weight (lb) Center-of-gravity (in.) Corner weight (% of total weight)
(a)
Min Max Length Width Corner A Corner B Corner C Corner D
Table 3. Typical unit weight, center of gravity, and corner weights (percentage of total weight) - air cooled DX units with
powered exhaust and ERV
Model Number
Weight (lb) Center-of-gravity (in.) Corner weight (% of total weight)
(a)
Min Max Length Width Corner A Corner B Corner C Corner D
OAK*144 4508 6337 79.1 35.0 22% 20% 31% 27%
OAK*180 4508 6337 80.5 36.8 23% 16% 35% 27%
OAK*210 4508 6337 81.3 37.4 24% 13% 36% 26%
OAK*240 4508 6337 82.5 37.5 26% 12% 37% 25%
OAK*264 4508 6337 81.2 37.2 22% 16% 34% 28%
OAK*300 4508 6337 76.7 35.5 22% 19% 34% 25%
