Unit Clearances, Curb Dimensions, and Dimensional Data
52 OAU-SVX007A-EN
OAD Units
Unit Clearances
Note: 72 in. (182.9 cm) clearance is required above the
condenser fans.
Note: 72 in. (182.9 cm) clearance is required above the
condenser fans.
Figure 82. Installation clearances for units with no
powered exhaust or ERV, in. (cm)
48.000
[121.9]
36.000
[91.4]
36.000
[91.4]
44.00
[111.3]
Figure 83. Installation clearances for unit with powered
exhaust but no ERV, in. (cm)
Figure 84. Installation clearances for unit with ERV, in.
(cm)
Figure 85. Unit to unit clearance, in. (cm)
36.00
[91.4]
36.00
[91.4]
36.00
[91.4]
48.00
[121.9]
48.000
[121.9]
60.000
[152.4]
36.000
[91.4]
36.000
[91.4]
84
(213.4)
84
(213.4)
