Installing the Tracer TD7 Display
This section describes installation procedures when installing the Tracer TD7 display inside a Trane
large enclosure, using a VESA mounting bracket, using the TD7 Display Portable Carry Case
(available as a separate purchase). Read and observe all warning and caution statements before
you begin the installation procedure.
The TD7 display can also be mounted remotely
up to 328 ft. (100
m.) from the UC600 by using a
field-supplied VESA mounting bracket (see “Installing the TD7 Display onto a VESA Mounting
Bracket,” p. 15).
WARNING
Hazardous Voltage!
Disconnect all electric power, including remote disconnects before servicing. Follow proper
lockout/tagout procedures to ensure the power can not be inadvertently energized. Failure to
disconnect power before servicing could result in death or serious injury.
Packaged Contents
• One (1) Tracer TD7 display with permanently attached 3.3 ft (1.0 m.) power cable with male
connector (PN: X13760335-01)
• Four (4) M-4 screws
• Four (4) spacer washers
• Two (2) 2-pin terminal blocks (one spare)
• One (1) 7 ft. (2.24 m.) category 5E
Ethernet
cable for indoor use
• One (1) 3.3 ft. (1 m.) power cable with female
connector (PN: X19051625020)
Additional Mounting Parts
• TD7 Display Low Profile Mounting Bracket (VESA 75mm) (PN: X05010511010)
• TD7 Display Portable Carry Case (PN: X1821
0613010)
• Sealed Ethernet cable (PN: X19070632020)
