BAS-SVX50F-EN 65
Overrides
Setting Up a Temporary Override
You can set up a temporary override by using the buttons in the Temporary Override area. The
default for temporary overrides is 2 hours 0 minutes. The maximum duration for a temporary
override is 99 hours 59 minutes. If more time is needed, consider setting up a permanent override.
1. Touch the Se
t to
Expire button.
A check mark appears in the check box, the override icon becomes blue, and the Time
Remaining area
appears.
2. Touch either the hours (HH) or minutes (MM) button, then use the
up and down arrows to set
the override.
• The HH and MM buttons, when pressed change by one increment. Press down on the buttons
to
accelerate. A second to
uch of the (HH) or (MM) buttons will open the Analog keypad screen.
Touch the Apply or Save button to set the temporary override.
