18
1e. Engine temperature gauge
The temperature gauge displays the engine
temperature in digital bars. There are six bars to
indicate the engine temperature. All the six bars will
be displayed if the engine temperature raises beyond
normal operating temperature and a diagnostic
message ‘ENGINE WARNING’ also will be displayed
at the alpha numeric display as shown.
On occurrence of the above error message, the
vehicle should be kept in idling for 10 minutes
approx. and switch ‘OFF’ the vehicle. If the problem
continues even after cooling the engine, take the
vehicle to TVS Motor Company Authorised Main
Dealer or Authorised Dealer and get it rectified.
1f. Helmet icon
With every ignition ‘ON’, Helmet icon ‘ ‘ blinks
for 10 seconds on the left side of the connected
instrument cluster to remind the rider to wear a
helmet.
1g. Low battery indicator
An icon with battery symbol ‘ ‘ glows when the
battery charge is too low. Get the battery checked
at TVS Motor Company Authorised Main Dealer /
Authorised Dealer.
1h. Service reminder
If the service is due, whenever the ignition is turned
‘ON’, a icon with spanner symbol ‘ ’ blinks for
10 seconds after the self-check cycle of connected
instrument cluster and continue to glow till the
vehicle is serviced and the reminder is reset. Get the
vehicle serviced at TVS Motor Company Authorised
Main Dealer / Authorised Dealer.
Low battery and service reminder indicator works on all
the modes of the connected instrument cluster.
