TVS NTORQ 125 User Manual

56
ENGINE OIL LEVEL
Check the engine oil level periodically.
1. Place the vehicle on centre stand on a flat surface.
Wipe-off the surroundings of gauge oil level.
2. Remove the gauge and wipe it clean.
3. Fix the gauge back to its mounting hole. Do not
thread in.
4. Take out the gauge and check the oil level. The
level should be between minimum and maximum
level marks of the gauge (shown in the figure).
5. If the oil is less than the minimum level, add ‘TVS
TRU4 SKUUTA oil (SAE 10W30 API-SL, JASO
MB)’ upto the maximum level mark.
6. Wipe out the oil traces with a clean cloth to
prevent dust accumulation.
7. Assemble back the gauge oil level.
If the vehicle is driven with less engine oil, the engine
components will be severely damaged.
Check the oil level as per the schedule to avoid costly
damage. Do not fill excess oil may cause oil leak. Always
use ‘TVS TRU4 SKUUTA oil (SAE 10W30 API-SL, JASO
MB)‘ only.
Caution
Maximum
Minimum

TVS NTORQ 125 Specifications

General

Displacement	124.8 cc
Max Torque	10.5 Nm @ 5, 500 rpm
Fuel System	Fuel Injection
Transmission	CVT
Front Brake	Disc
Rear Brake	Drum
Kerb Weight	118 kg
Front Tyre	100/80-12
Rear Tyre	110/80-12
Starting Method	Electric Start
Tyre Type	Tubeless
Seat Height	770 mm
Ground Clearance	155 mm
Engine Type	Single Cylinder, 4-Stroke, Air Cooled
Front Suspension	Telescopic
Fuel Tank Capacity	5.8 liters
Wheelbase	1285 mm
Rear Suspension	Coil Spring, Hydraulic Damped
