TVS NTORQ 125 User Manual

60
Front brake - Disc brake SBS type
You can observe a master cylinder (1) right side of the
handle bar under the head lamp housing.
A caliper assembly (2) fitted to the fork leg L, a disc
(3) on the front wheel and a high pressure hose
(4) connecting the master cylinder and the caliper
assembly.
1. Check the master cylinder brake fluid level
through the view piece glass (A).
2. The brake fluid level always should be above the
‘LOWER’ mark (B) provided on the view piece
glass of the master cylinder when the cylinder is
parallel to ground.
3. If the brake fluid level is below the mark or while
applying brake if you feel the brake is more
spongy or ineffective due to air entry, contact
TVS Motor Company Authorised Main Dealer or
Authorised Dealer for topping-up the brake fluid,
air bleeding and other brake related inspections.
Master cylinder brake fluid level must be checked only
when the master cylinder is parallel to the ground.
Caution
4
B
3
1
A
2

TVS NTORQ 125 Specifications

General

Displacement	124.8 cc
Max Torque	10.5 Nm @ 5, 500 rpm
Fuel System	Fuel Injection
Transmission	CVT
Front Brake	Disc
Rear Brake	Drum
Kerb Weight	118 kg
Front Tyre	100/80-12
Rear Tyre	110/80-12
Starting Method	Electric Start
Tyre Type	Tubeless
Seat Height	770 mm
Ground Clearance	155 mm
Engine Type	Single Cylinder, 4-Stroke, Air Cooled
Front Suspension	Telescopic
Fuel Tank Capacity	5.8 liters
Wheelbase	1285 mm
Rear Suspension	Coil Spring, Hydraulic Damped
