TVS NTORQ 125 User Manual

57
TRANSMISSION OIL - LEVEL
Check the transmission oil level periodically.
1. Place the vehicle on centre stand on a flat surface.
2. Wipe-off the surroundings of oil level screw.
3. Remove the transmission oil level screw along
with a gasket from the rear end of crankcase L.
4. Check for the flow of oil from oil level hole.
5. If the level is less (if there is no oil flow), top-up
with ‘TVS TRU4 SKUUTA oil (SAE 10W30 API-SL,
JASO MB)’ till the oil just starts to flow out from
the oil level hole.
6. Wipe out the oil traces with a clean cloth to
prevent dust accumulation.
7. Replace the fibre washer while reassembling the
oil level screw.
If the vehicle is driven with less transmission oil, the
transmission components of engine will be severely
damaged.
Check the oil level as per the schedule to avoid costly
damage. Do not fill excess oil may cause oil leak. Always
use ‘TVS TRU4 SKUUTA oil (SAE 10W30 API-SL, JASO
MB)‘ only.
Caution

TVS NTORQ 125 Specifications

General

Displacement	124.8 cc
Max Torque	10.5 Nm @ 5, 500 rpm
Fuel System	Fuel Injection
Transmission	CVT
Front Brake	Disc
Rear Brake	Drum
Kerb Weight	118 kg
Front Tyre	100/80-12
Rear Tyre	110/80-12
Starting Method	Electric Start
Tyre Type	Tubeless
Seat Height	770 mm
Ground Clearance	155 mm
Engine Type	Single Cylinder, 4-Stroke, Air Cooled
Front Suspension	Telescopic
Fuel Tank Capacity	5.8 liters
Wheelbase	1285 mm
Rear Suspension	Coil Spring, Hydraulic Damped
