TVS NTORQ 125 User Manual

51
APPLICATION QTY MANUFACTURER BRAND
Engine oil
880 ml (during regular service)
930 ml (incase of disassembly)
TVS Motor Company
TVS TRU4 SKUUTA oil
(SAE 10W30 API-SL, JASO MB)
Transmission oil
120 ml (during regular service)
130 ml (incase of disassembly)
-do- -do-
Front fork oil 91 ± 1 cc / leg IOC / HPCL Gabriel front fork fluid
Disc brake fluid (only for Disc brake version) – TVS Girling DOT 3 / DOT 4
Grease –
Bharat petroleum
IOC
Bechem
Kluber ubrication
MP Grease no. 3
Servo Gem no. 3
Bechem premium 3
Kluber Centoplex 2
Fuel additives As recommended IFTEX
RECOMMENDED LUBRICANTS
Item
Service
km
Period from the date of sale
In free service After free service
Remarks
1st
500 - 750
2 months
2nd
2500 - 3000
4 months
3rd
5000 - 6000
8 months
4th
8500 - 9000
12 months
Every
3000 km
Every
6000 km
Engine idling RPM I & S I & S I & S I & S I & S –
Idling CO%
7
I & S – – – – –
Centre / side stand pivot L L L L L – Lubricate using TRU4 oil
Kick starter pedal pivot L L L L L – Lubricate using TRU4 oil
7
Idling CO% should be set with the help of exhaust gas analyser and tachometer only
R - Replace; I - Inspect; T - Top up; C - Clean; A - Adjust; DR - Drain; L - Lubricate; TI - Tighten; S - Set

TVS NTORQ 125 Specifications

General

Displacement	124.8 cc
Max Torque	10.5 Nm @ 5, 500 rpm
Fuel System	Fuel Injection
Transmission	CVT
Front Brake	Disc
Rear Brake	Drum
Kerb Weight	118 kg
Front Tyre	100/80-12
Rear Tyre	110/80-12
Starting Method	Electric Start
Tyre Type	Tubeless
Seat Height	770 mm
Ground Clearance	155 mm
Engine Type	Single Cylinder, 4-Stroke, Air Cooled
Front Suspension	Telescopic
Fuel Tank Capacity	5.8 liters
Wheelbase	1285 mm
Rear Suspension	Coil Spring, Hydraulic Damped
