Vatech PaX-i3D Smart User Manual

12. Technical Specifications
125 I
PaX-i3D Smart
English
12.2 Technical Specifications
❚
X-Ray Generator
Item Description
Model DG-07C11T2
Rated output power 1.6KW (1sec)
High Voltage
Generator
Type Inverter Type
Normal / Pulse
50 ~ 99 kV (Max. 99kV 10mA)
4 ~ 16 mA (Max 75kV 16mA)
0.5 ~ 20 sec
Cooling
Automatically controlled / Protect
≥ 60°C
Cooling Fan : Optional
Added Filtration (mmAl) 2.0 mm Al eq.
Total Filtration (mmAl) 2.8 mm Al eq.
X-ray tube
Model Name D-052SB(Stationary Anode Type)
Manufacturer Toshiba
Focal Spot (mm) 0.5mm x 0.5mm (IEC60336)
Inherent Filtration (mmAl) At least 0.8 mm Al eq. at 50 kV
Target angle 5 °
X- ray Coverage 95 x 380 mm at SID 550 mm
Anode Heat Content 35 kJ
Duty Cycle
1:60 or more (Exposure time :
Interval time)
Weight
INV-11 Inverter 1.35 kg
DG-07CT2(H-Type)
Monotank
12.5 kg
