5-10
BA ET16 de*
1.0 *
et16b500.fm
5
Operation
Rot
ating beacon (option)
The rotating beacon has a ma
gnetic base and is attached to the cabin
roof. The e
lectric pow
er supply oc
curs via the
12 volt plug rece
ptacle
A.
Information
Observe the national and regional regula
tions.
Information
With the attached FOPS screen category II, no rotating
beacon can be
attached.
Horn
Press touch control
A
on the right-hand
control lever to actuate the horn.
Fig. 1
15 (symbolic represen
tation)
A
A
111
113
