5-54
BA ET16 de*
1.0 *
et16b510.fm
5
Operation
Shovel bucket operation
Wacker Neuson backhoe buckets can also be used for shovel bucket
operation.
NOTICE
The stick can be damaged if it is hit by the bucket base.
►
Do not tilt out the bucket completely
if it is used as a shov
el bucket.
T
railer operation
The machine is not certif
ied for trailer operation.
Fig. 195
155
157
