BA ET16 de* 1.0 * et16t900.fm
9-5
Technical data
9
Main fuse box
The main fuses and the relay are locate
d in the engine compartment.
Remove the screw
A
and remov
e the batte
ry cover.
Fig. 247
A
Fuses/relays
ET16
F1
Main fuse 40
A; air-
pressure sens
or/output
adaptation (Yanmar 3
TNV80F-SSNS2)
K6
Preheating time lag relay
K7
Start switching relay
K8
Time lag relay 1s cut-off solenoid
K9
Cut-off solenoid switching relay
Fig. 248
F1
K7
K8
K9
K6
222
224
