BA ET16 de* 1.0 * et16i400.fm
4-11
Putting into operation
4
Fastening the
retracting
lap belt
Insert buckle latch
A
into s
eat belt buc
kle
B
until it engages.
Unfasten
ing the retra
cting seat
belt
Press the red push button
D
on seat belt buckle
B
until the
buckle latch
comes out.
➥
Seat belt
C
is
automatically retracted.
Fig. 80
A
B
Fig. 81
D
B
C
70
72
