Drive unit/diesel engine
48
BA RD24_RD27 en 04
2.03 Drive unit/diesel engine
3 6
421
75
[1] Fuel system [2] Oil dipstick
[3] Oil inlet [4] Diesel engine with drive units
[5] Air filter [6] Coolant inlet
[7] Coolant level indicator
23
54
6
1
[1] Air filter [2] Dust discharge valve
[3] Cooling system [4] Diesel engine oil outlet
[5] Exhaust system [6] V-belt protection
