L3130 · L3430 · L3830 · L4630 · L5030, WSM
TRANSMISSION
2. SERVICING SPECIFICATIONS
[1] GENERAL
W1013874
Item Factory Specification Allowable Limit
Gear to Spline Clearance 0.030 to 0.078 mm
0.00118 to 0.00307 in.
0.2 mm
0.008 in.
Shift Fork to Shifter Gear Groove Clearance 0.20 to 0.40 mm
0.008 to 0.016 in.
0.8 mm
0.031 in.
Gear to Shaft Clearance 0.021 to 0.054 mm
0.00083 to 0.00213 in.
0.1 mm
0.004 in.
Shift Fork to Shifter Groove Clearance
(Shuttle)
(Others)
0.20 to 0.45 mm
0.0079 to 0.0177 in.
0.15 to 0.40 mm
0.0059 to 0.0157 in.
0.8 mm
0.031 in.
0.8 mm
0.031 in.
Synchronizer Ring to Gear (In Contact) Side Clearance – 0.35 mm
0.0138 in.
Spiral Bevel Gear Turning Torque 3.92 to 6.37 N·m
0.40 to 0.65 kgf·m
2.89 to 4.70 ft-lbs
Spiral Bevel Pinion to Spiral Bevel Gear Backlash
Tooth Contact
Center to Tooth
Contact
0.15 to 0.30 mm
0.006 to 0.012 in.
–
–
–
More than 35 %
1/3 to 1/2 of the
entire width from
the small end
Differential Case Bore (Differential Case
Cover Bore) to Differential Side Gear Boss
Differential Case Bore
Differential Case Cover Bore
Differential Side Gear Boss
Clearance
I.D.
I.D.
O.D.
0.050 to 0.151 mm
0.00197 to 0.00594 in.
40.500 to 40.550 mm
1.59449 to 1.59646 in.
40.500 to 40.550 mm
1.59449 to 1.59646
40.338 to 40.450 mm
1.59008 to 1.59252 in.
0.35 mm
0.0138 in.
–
–
–
Differential Pinion Shaft to Differential
Pinion
Differential Pinion Shaft
Differential Pinion
Clearance
O.D.
I.D.
0.060 to 0.102 mm
0.00236 to 0.00402 in.
19.959 to 19.980 mm
0.78579 to 0.78661 in.
20.040 to 20.061 mm
0.78898 to 0.78980 in.
0.25 mm
0.0098 in.
–
–
