3-S14
L3130 · L3430 · L3830 · L4630 · L5030, WSM
TRANSMISSION
[4] HST
W1277262
Item Factory Specification Allowable Limit
Check and High Pressure Relief Valve
Condition
• Engine Speed : Maximum
• Oil Temperature : 40 to 60 °C
104 to 140 °F
• Range Gear Shift Lever : H Position
• HST Pedal : Depress Forward or
Reverse with Brake
Setting Pressure 33.3 to 36.3 MPa
340 to 370 kgf/cm
2
4836 to 5262 psi
–
Charge Relief Valve
Condition
• Engine Speed : Maximum
• Oil Temperature : 40 to 60 °C
104 to 140 °F
• HST Pedal : Neutral
Setting Pressure 2.26 to 2.45 MPa
23 to 25 kgf/cm
2
327 to 355 psi
–
Cruise Control Lever Operating Force
(Forward
Direction)
54 to 64 N
5.5 to 6.5 kgf
12.1 to 14.3 lbs
–
KiSC issued 02, 2007 A
