9-M32
L3130 · L3430 · L3830 · L4630 · L5030, WSM
ELECTRICAL SYSTEM
4. CHARGING SYSTEM
(1) Battery
(2) Slow Blow Fuse
(ROPS : 60 A, Cabin : 80 A)
(3) Main Switch (for ROPS)
(4) Main Switch (for Cabin)
(5) Engine Tachometer Sensor
(6) Electronic Instrument Panel
(IntelliPanel)
(7) ECU (GST Model Only)
(8) Alternator
KiSC issued 02, 2007 A
