Page 19F
T-991
DOWN
UP
+5V
MIC GND
MIC
PTT
GND
FAST
① DCD
② SERIAL OUT/RXD
（GPS DATA IN）
③ SERIAL IN
④ DTR
⑤ GND
⑥ DSR
⑦ RTS
⑧ CTS
⑨ RI
①②③④⑤
⑧⑨ ⑦ ⑥
(
as viewed from front panel
) (
as viewed from rear panel
)
① DATA IN
② GND
③ PTT
④ SHIFT
⑤ DATA OUT
⑥ SQL
① ②
③ ④
⑤
⑥
+13V OUT
TX GND
GND
TX D (BAND A)
RX D (BAND B)
BAND C
TX INH
(
as viewed from rear panel
) (
as viewed from rear panel
)
KEY
Manipulator Single key/Double-speed key
DOT KEY GNDDASH COMMON
(
as viewed from rear panel
)
Do not use
2-conductor type plug
SIGNAL GND
SIGNAL (LEFT)
SIGNAL (RIGHT)
GND
EXT ALC
TX REQ
GND
REMOTE
NC
GND
To Next Page
