2.1 How to Read the Catalog Code
YASKAWA TOEPC71061779E GA800 DRIVE INSTALLATION MANUAL
13
2.1 How to Read the Catalog Code
Use the information in Figure 2.2 and Table 2.1 to read the drive catalog codes.
Figure 2.2 Drive Catalog Code
Table 2.1 Catalog Code Details
No. Description
1 GA800 Series
2 Region code
• U: Americas
3 Input power supply voltage
• 2: Three-Phase AC 240 V
• 4: Three-Phase AC 480 V
• 5: Three-Phase AC 600 V
• T: 6-Phase/12-Pulse AC 400 V
4 Rated output current
Note:
Refer to the rated output current list for more information.
5
EMC noise filter
• A: No built-in EMC filter
• B: Internal category C3 EMC filter
6 Protection design
• A: IP00/UL Open Type
• B: IP20/UL Open Type
• F: IP20/UL Type 1
• T: IP55/UL Type 12
• W: IP55/UL Type 12 Heatsink External Mounting
7 Environmental specification
• M: Resistant to dust/humidity
