4.1 Replace Cooling Fans and Circulation Fans
YASKAWA TOEPC71061779E GA800 DRIVE INSTALLATION MANUAL
41
4.1 Replace Cooling Fans and Circulation Fans
CAUTION
Injury to Personnel
Some fan units are not easily accessible from a standing position. Make sure that you can safely
and comfortably remove and replace the fan.
If you try to remove a fan that you cannot easily access, the fan unit can fall and cause minor to moderate injury.
NOTICE
Use the instructions in this manual to replace the cooling fans. When you do maintenance on the
fans, replace all the fans to increase product life.
If you install the fans incorrectly, it can cause damage to the drive.
◆ Cooling Fans and Circulation Fans by Drive Model
Table 4.1 Cooling Fans and Circulation Fans
Model Cooling Fan Circulation Fan
Circuit Board Cooling
Fan
Procedure Ref.
2004 - 2012
4002 - 4005
- - - - -
2018, 2021
4007 - 4012
1 - - Procedure A 42
2030, 2042
4018, 4023
2 - - Procedure B 44
2056 - 2082
4031 - 4060
2 - - Procedure C
47
2110 - 2211
4075 - 4168
T103 - T168
2 - - Procedure D
49
2257 - 2313
4208 - 4302
5125, 5144
T208 - T302
2 - - Procedure E
52
4371
T371
2 1 - Procedure F 55
2360, 2415
4414
5192 - 5289
T414
3 1 - Procedure F 55
4477 - 4605
T477 - T605
2 1 2 Procedure G 61
4720
5382 - 5472
T720
3 1 2 Procedure H 70
