YASKAWA GA800 GA80U Series User Manual

5.1 Common Drive Specifications
82
YASKAWA TOEPC71061779E GA800 DRIVE INSTALLATION MANUAL
5.1 Common Drive Specifications
Note:
• To get the OLV, CLV, and AOLV specifications, do Rotational Auto-Tuning.
• To get the longest product life, install the drive in an environment that meets the necessary specifications.
Table 5.1 Control Characteristics
Item Specification
Control Methods
• V/f Control (V/f)
• V/f Control with Encoder (CL-V/f)
• Open Loop Vector (OLV)
• Closed Loop Vector (CLV)
• Advanced Open Loop Vector (AOLV)
• PM Open Loop Vector (OLV/PM)
*1
• PM Advanced Open Loop Vector (AOLV/PM)
*1
• PM Closed Loop Vector (CLV/PM)
*1
• EZ Vector Control (EZOLV)
*1
Carrier Frequency
• Models 2004 to 2138, 4002 to 4103, and T103
HD: 8 kHz without derating the drive capacity.
ND: 2 kHz without derating the drive capacity.
Derate the drive capacity to use values to 15 kHz maximum.
• Models 2169 to 2415, 4140 to 4414, and T140 to T414
HD: 5 kHz without derating the drive capacity.
ND: 2 kHz without derating the drive capacity.
Derate the drive capacity to use values to 10 kHz maximum.
• Models 4477 to 4720, and T477 to T720
HD: 2 kHz without derating the drive capacity.
ND: 2 kHz without derating the drive capacity.
Derate the drive capacity to use values to 5 kHz maximum.
• Models 5125 to 5472
2 kHz without derating the drive capacity.
Maximum Output
Voltage
• 200 V Class: Three-Phase 200 V to 240 V
• 400 V Class: Three-Phase 380 V to 480 V
• 600 V Class: Three-Phase 500 V to 600 V
Note:
The maximum output voltage is proportional to the input voltage.
Frequency Control
Range
• AOLV and EZOLV: 0.01 Hz to 120 Hz
• CL-V/f, CLV, AOLV/PM, and CLV/PM: 0.01 Hz to 400 Hz
• V/f, OLV, and OLV/PM: 0.01 Hz to 590 Hz
Frequency Accuracy
(Temperature
Fluctuation)
Digital inputs: Within ±0.01% of the maximum output frequency (-10 °C to +40 °C (14 °F to 104 °F))
Analog inputs: Within ±0.1% of the maximum output frequency (25 °C ±10 °C (77 °F ±18 °F))
Frequency Setting
Resolution
Digital inputs: 0.01 Hz
Analog inputs: 1/2048 of the maximum output frequency (11-bit signed)
Output Frequency
Resolution
0.001 Hz
Frequency Setting
Signal
Main speed frequency reference: -10 Vdc to +10 Vdc (20 kΩ), 0 Vdc to 10 Vdc (20 kΩ), 4 mA to 20 mA (250 Ω), 0 mA to 20 mA (250 Ω)
Main speed reference: Pulse train input (maximum 32 kHz)
Starting Torque
• V/f: 150%/3 Hz
• CL-V/f: 150%/3 Hz
• OLV: 200%/0.3 Hz
• CLV: 200%/0 min
-1
(r/min)
• AOLV: 200%/0.3 Hz
• OLV/PM: 100%/5% speed
• AOLV/PM: 200%/0 min
-1
(r/min)
• CLV/PM: 200%/0 min
-1
(r/min)
• EZOLV: 100%/1% speed
Note:
• Correctly select the drive and motor capacity for this starting torque in these control methods:
–OLV
–CLV
–AOLV
–AOLV/PM
–CLV/PM
• Set n8-57 = 1 [HFI Overlap Selection = Enabled] for this starting torque in AOLV/PM. When you use a non-Yaskawa PM motor, do Rotational Auto-
Tuning.

YASKAWA GA800 GA80U Series Specifications

General

Series	GA800 GA80U Series
Output Voltage	Matches Input Voltage
Power Range	0.4kW to 1.5MW
Power Rating	0.4 kW to 450 kW
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Cooling Method	Air Cooled
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat, Short circuit
Communication	Ethernet, Modbus, DeviceNet, Profibus, CC-Link
Safety	STO (Safe Torque Off)
Operating Temperature	+50°C
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20, IP00
