YASKAWA GA800 GA80U Series User Manual

3.3 IP55/UL Type 12 Heatsink External Mounting Drive Dimensions
18
YASKAWA TOEPC71061779E GA800 DRIVE INSTALLATION MANUAL
3.3 IP55/UL Type 12 Heatsink External Mounting Drive
Dimensions
◆ Models 2004 to 2110, 4002 to 4075
Figure 3.1 Dimension Diagram 1
Model
Dimensions mm (in)
W H D D1 W1 W2 W3 H1 H3 H4 H5 d1 d2
2004 -
2012
4002 -
4005
178
(7.01)
294
(11.57)
176
(6.93)
38
(1.50)
102
(4.02)
102
(4.02)
166
(6.54)
282
(11.10)
88
(3.46)
102
(4.02)
6
(0.24)
M5 M5
2018 -
2042
4007 -
4023
178
(7.01)
294
(11.57)
211
(8.31)
73
(2.87)
102
(4.02)
102
(4.02)
166
(6.54)
282
(11.10)
88
(3.46)
102
(4.02)
6
(0.24)
M5 M5
2056
4031, 4038
218
(8.58)
329
(12.95)
202
(7.95)
68
(2.68)
140
(5.51)
140
(5.51)
206
(8.11)
318
(12.52)
81.9
(3.22)
129
(5.08)
5
(0.20)
M5 M5
2070, 2082
4044
258
(10.16)
384
(15.12)
227
(8.94)
87
(3.43)
192
(7.56)
192
(7.56)
246
(9.69)
371
(14.61)
114.5
(4.51)
150
(5.91)
7
(0.28)
M6 M5
4060
258
(10.16)
384
(15.12)
246
(9.69)
106
(4.17)
192
(7.56)
192
(7.56)
246
(9.69)
371
(14.61)
114.5
(4.51)
150
(5.91)
7
(0.28)
M6 M5
2110
4075
277.5
(10.93)
400
(15.75)
280
(11.02)
114
(4.49)
195
(7.68)
204
(8.03)
265.5
(10.45)
385
(15.16)
112.5
(4.43)
160
(6.30)
7.5
(0.30)
M6 M5
