3.3 IP55/UL Type 12 Heatsink External Mounting Drive Dimensions
20
YASKAWA TOEPC71061779E GA800 DRIVE INSTALLATION MANUAL
◆ Models 2169, 2211, 4140, 4168, T140, T168
Figure 3.3 Dimension Diagram 3
Model
Dimensions mm (in)
W H D D1 W1 W2 W3 H1 H3 H4 H5 d1 d2
2169, 2211
4140, 4168
T140,
T168
302
(11.89)
543
(21.38)
335
(13.19)
149
(5.87)
190
(7.48)
220
(8.66)
290
(11.42)
527
(20.75)
53
(2.09)
140
(5.51)
8.5
(0.33)
M8 M5
