3.3 IP55/UL Type 12 Heatsink External Mounting Drive Dimensions
22
YASKAWA TOEPC71061779E GA800 DRIVE INSTALLATION MANUAL
◆ Models 2360, 2415, 4371, 4414, 5192 to 5289, T371, T414
Figure 3.5 Dimension Diagram 5
Model
Dimensions mm (in)
W H D D1 W1 W2 W3 H1 H3 H4 H5 d1 d2
2360, 2415
4371, 4414
5192 -
5289
T371,
T414
478
(18.82)
800
(31.50)
472
(18.58)
218
(8.58)
370
(14.57)
310
(12.20)
466
(18.35)
773
(30.43)
106.5
(4.19)
140
(5.51)
14
(0.55)
M12 M5
