5.2 Drive Derating
86
YASKAWA TOEPC71061779E GA800 DRIVE INSTALLATION MANUAL
5.2 Drive Derating
You must derate the drive capacity to operate the drive above the rated temperature, altitude, and default carrier
frequency.
◆ Carrier Frequency Settings and Rated Current Values
Table 5.5, Table 5.8, Table 5.11 and Table 5.13 show how the drive rated output current changes when the C6-02
[Carrier Frequency Selection] value changes when A1-02 ≠ 4 or 6.
The output current value changes linearly as the carrier frequency changes. You can use the values from the tables to
calculate a frequency that is not shown. When A1-02 = 4 [Control Method Selection = AOLV], refer to Table 5.6,
Table 5.9, Table 5.12 and Table 5.14.
When A1-02 = 6 [AOLV/ PM], refer to Table 5.7, Table 5.10, and Table 5.15.
■ Three-Phase 200 V Class
Table 5.5 Carrier Frequency and Rated Current Derating When A1-02 = 0, 1, 2, 3, 5, 7, 8
Model
Rated Current (A)
Heavy Duty Rating (HD)
C6-01 = 0
Normal Duty Rating (ND)
C6-01 = 1
2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 15 kHz 2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 15 kHz
2004
3.5 3.5 3.5 3.4 3.2 3.06 4.2 4.0 3.6 3.4 3.1 2.77
2006
5.0 5.0 5.0 4.8 4.6 4.3 6 5.6 5 4.6 4.1 3.6
2008
6.9 6.9 6.9 6.5 5.9 5.4 8 7.6 6.9 6.5 5.9 5.4
2010
8.0 8.0 8.0 7.4 6.6 5.8 9.6 9.0 8 7.4 6.6 5.8
2012
11.0 11.0 11.0 10.4 9.6 8.8 12 11.7 11 10.5 9.9 9.3
2018
14.0 14.0 14.0 12.6 10.8 9.1 17.5 16.1 14 12.6 10.8 9.1
2021
17.5 17.5 17.5 16.1 14.3 12.6 21 19.6 17 16.1 14.3 12.5
2030
25.0 25.0 25.0 23.0 20.5 18.0 30 28.0 25 23.0 20.5 18.0
2042
33.0 33.0 33.0 29.3 24.8 20.2 42 38.4 33 29.4 24.9 20.4
2056
47.0 47.0 47.0 43.4 38.9 34.4 56 52.4 47 43.4 38.9 34.4
2070
60.0 60.0 60.0 56.0 51.0 46 70 66.0 60 56.0 51.0 46.0
2082
75.0 75.0 75.0 68.6 60.5 53 82 82.0 75 68.8 61.0 53.1
2110
88.0 88.0 88.0 80.5 71.0 62 110 102.7 92 84.3 75.2 66.0
2138
115.0 115.0 115.0 105.1 92.8 81 138 128.8 115 105.8 94.3 82.8
2169
145.0 145.0 125.2 112.0 - - 169 152.7 128.3 112.0 - -
2211
180.0 180.0 155.2 138.6 - - 211 190.2 158.9 138.1 - -
2257
215.0 215.0 184.8 164.7 - - 257 230.4 190.5 163.9 - -
2313
283.0 283.0 249.0 226.4 - - 313 288.5 251.7 227.1 - -
2360
346.0 346.0 294.3 259.8 - - 360 330.8 287.6 258.8 - -
2415
415.0 415.0 365.2 332.0 - - - - - - - -
Table 5.6 Carrier Frequency and Rated Current Derating When A1-02 = 4 [AOLV]
Model
Rated Current (A)
Heavy Duty Rating (HD)
C6-01 = 0
Normal Duty Rating (ND)
C6-01 = 1
2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz
2004
3.5 3.5 3.2 3.1 2.8 4.2 3.7 3.1 2.8 2.3
2006
5.0 5.0 4.6 4.3 4.0 6 5.1 4 3.6 2.8
