YOKOGAWA CW240 User Manual

6-3
IM CW240E
Configuring Settings
6
6.1 Settings
● Setting Items
General
1/2 2/2 1/2 2/2
Save
VAR METHOD
SAMPLING METHOD
FREQUENCY SOURCE
AVERAGE TIMES
ZERO CROSS FILTER
Wh DISPLAY
Position of decimal point
and unit of measurement
INTERVAL Wh DISP.
Position of decimal point
and unit of measurement
THD MEASURE METHOD
PA CALC. METHOD
HARM. GRAPH ORDER
WIRING
LOAD
(1P CONNECT)
U RANGE
VT
A RANGE
CT
CLAMP
MEASURE
START/STOP
SAVE
INTER.
(Interval time)
DATA SAVE
HARD COPY
FILE NAME
Save/Not to save
E.ENERGY/DEM.
WAVEFORM DATA
NORMAL MEAS.
HARM. MEAS.
HARM. MEAS. DETA.
INST.
AVE.
MAX.
MIN.
Communication Volt. Quality Hardware
RS-232 CONNECT
BAUD RATE
DATA LENGTH
PARITY
STOP BIT
FLOW CONTROL
Measure/Not to measure
STANDARD VOLTAGE
Threshold value
SWELL
DIP
INTERRUPTION
HYSTERESIS
LANGUAGE
BEEP
BACKLIGHT AUTO OFF
LCD CONTRAST
ID NUMBER
DATE AND TIME
For more information on the setting procedure of the following, see the chapters
below:
General Settings 1/2 Section 6.2
General Settings 2/2 Section 6.3
Save Data Settings 1/2 Section 6.4
Save Data Settings 2/2 Section 6.5
Communication Settings Section 6.6
Voltage Quality Settings Section 6.7
Hardware Settings Section 6.8
Analog I/O Settings Section 6.9
