15-3
IM CW240E
Other Functions
15
15.2 Turning the LCD Backlight ON
and OFF
● Turning the LCD Backlight ON
<Turning the light ON>
LIGHT
Press the LIGHT key.
The LCD backlight is lit.
The backlight will also be lit if the LIGHT key is pressed when the backlight
has been turned off by the auto-off function.
<Turning the light OFF>
Press the LIGHT key when the light is ON.
The LCD backlight will go OFF.
● LCD Backlight Auto-off Function
This function automatically turns the LCD backlight OFF when there has been
no key operation for 10 minutes or more while the LCD backlight is lit. (Set with
hardware.)
TOP
MENU
ENTER
LIGHT
TOP
MENU
SAVE
A
RANGE
START
&STOP
ESC
ENTER
F
1
F
2
F
3
F
4
F
5
DISP COPY
RANGE
ENTER
[ 1 Displaying the Hardware screen
Using the right and left cursor keys, select the Hardware tab
(highlighted).
Using the up and down cursor keys, select BACKLIGHT AUTO OFF.
[ 2 Setup
F
1
F
1
,
F
2
Press the corresponding function key to activate/deactivate auto
backlight OFF.
F1 : ON Activates auto backlight OFF if no key is pressed for more than
10 minutes.
F2 : OFF Lets the backlight remain ON.
To Next Page
